IRIDIUM WIRELESS Basic People Counter
The transmitter unit transmits an infrared beam to the receiver unit. When someone passes between the 2 units and
breaks the infrared beam, the count value increases by one. Because of the single infrared beam, this counter is not
direction sensitive. Users of this system simply divide the total daily count by 2. This wireless, portable People
Counter is equipped with a screen that displays the current count. Bi-directional (2 beam) Display Counters are
available.
◉ Dimensions – 80(100) x 60 x 25 mm
◉ Material – ABS Plastic – Black, silver
◉ Power supply – 3 x 3.6V AA Lithium
◉ Power consumption – +/- 60 uA
◉ Battery life – 2 years
◉ Maximum counting distance – (12 m)
◉ Maximum count value – 999999
◉ Completely Wireless
◉ Easy to install (plug and play)
◉ Mounting on almost any surface
◉ Small and lightweight transmitter and receiver units
◉ Batteries included
Drawings and technical information of this data sheets issued for marketing purposes only and may not be reproduced or used to manufacture anything shown or referred to hereon without permission from IRIDIUM LTD.
