IRIDIUM WIRELESS People Counter WLAN:
The transmitter unit transmits an infrared beam to the receiver unit. When someone passes between the 2 units and
breaks the infrared beam, the internal counter increases by one. Because of the single infrared beam, this counter is not
direction sensitive. The count values are available within adjutable time and are viewed on a local or remote PC with the
use of our Central unit.
◉ Dimensions – 80(100) x 60 x 25 mm
◉ Material – ABS Plastic – Black, Silver
◉ Power supply – 3 x 3,6V AA Lithium
◉ Power consumption – Approximately 120 uA
◉ Battery life – 1.5 year
◉ Maximum counting distance – 12 m
◉ RF Frequency – 433 MHz
◉ Wireless Range – 100 m / Repeater for increasing distance is available
◉ Completely Wireless
◉ Counting Data can be viewed and managed on a local or remote computer
◉ Easy to install (plug and play)
◉ Mounting on almost any surface
◉ Small and lightweight transmitter and receiver units
◉ Batteries included
Software for RF sensor receiver for People Counter WLAN:
◉ Counting data to be connected to a PC to view and manage the data.
◉ Microsoft Windows XP or later (ready for Windows 8.1)
◉ Microsoft .NET 4.0 or later
◉ Web-based or Interface
◉ Free software license
Drawings and technical information of this data sheets issued for marketing purposes only and may not be reproduced or used to manufacture anything shown or referred to hereon without permission from IRIDIUM LTD.
